Emagram Analysis vs Temperature

TEMP GND
C
THRML TOP
m
CLD BASE
m
AVAIL ALT
m
DRCT
deg
SKNT
knot
TEMP AIR
C
---------------------------------------------------------------------------------
11 0 0 0 - - -
12 0 0 0 - - -
13 0 0 0 - - -
14 0 0 0 - - -
15 0 0 0 - - -
16 0 0 0 - - -
17 0 0 0 - - -
18 0 0 0 - - -
19 0 38 0 - - -
20 0 163 0 - - -
21 0 288 0 - - -
22 0 413 0 - - -
23 227 538 227 155 6 19.5
24 557 663 557 125 8 18.4
25 727 788 727 125 16 17.6
---------------------------------------------------------------------------------

Forecast Information 2024/05/31 Kagoshima,Kagoshima

MaxTemp : 20.67
DewPoint : 18.7

Emagram Analysis vs Time

Time
C
TEMP
GND
m
Dew
Point
C
Thermal Top
m
CLD BASE
m
AVAIL
ALT
m
CLD
%
Wind
deg
Wind
m/s
CLD BASE LCL
m
----------------------------------------------------------------------------------------------------------------------
07:00 20.38 20.05 0 163 0 100 338 1.43 41
08:00 20.26 19.93 0 163 0 100 338 1.2 41
09:00 20.23 19.74 0 163 0 100 4 1.14 61
10:00 20.36 19.87 0 163 0 100 6 1.24 61
11:00 20.4 19.91 0 163 0 100 39 1.36 61
12:00 20.46 19.55 0 163 0 100 12 0.91 114
13:00 20.61 19.66 0 288 0 100 303 1.63 119
14:00 20.35 19.42 0 163 0 100 323 1.55 116
15:00 20.67 19.24 0 288 0 100 333 1.54 179
16:00 20.27 19.12 0 163 0 100 326 1.17 144
----------------------------------------------------------------------------------------------------------------------

Emagram GIF Data 2024053012 Kagoshima

Emagram Source Data 2024053012 Kagoshima

-----------------------------------------------------------------------------
   PRES   HGHT   TEMP   DWPT   RELH   MIXR   DRCT   SKNT   THTA   THTE   THTV
    hPa     m      C      C      %    g/kg    deg   knot     K      K      K
-----------------------------------------------------------------------------
 1011.0     31   22.6   18.8     79  13.70     40      6  294.8  334.2  297.2
 1010.0     37   22.5   18.7     79  13.62      0      0  294.8  334.0  297.2
 1006.0     61   22.2   18.3     78  13.29     65      6  294.9  333.2  297.2
 1000.0     97   21.8   17.6     77  12.82     50      6  294.9  331.9  297.2
  992.0    166   21.2   17.5     79  12.87     35      4  295.1  332.2  297.4
  967.0    387   19.5   17.3     87  13.03    155      6  295.5  333.1  297.8
  954.0    504   18.6   17.2     92  13.11    136      7  295.7  333.6  298.0
  947.0    567   18.4   17.0     92  13.07    125      8  296.1  333.9  298.4
  932.0    704   17.8   16.7     93  12.97    140     12  296.9  334.6  299.2
  925.0    769   17.6   16.5     93  12.93    125     16  297.3  334.9  299.6
  923.0    787   17.6   16.5     93  12.92    130     16  297.4  335.1  299.8
  905.0    956   17.2   16.1     93  12.88    158     16  298.8  336.5  301.1
  876.0   1234   17.4   16.4     94  13.58    204     16  301.8  342.0  304.2
  869.0   1302   17.1   16.1     94  13.45    215     16  302.1  342.0  304.6
  850.0   1491   16.2   15.4     95  13.11    205     17  303.1  342.2  305.5
  821.0   1783   14.7   13.9     95  12.32    220     17  304.6  341.6  306.8
  801.0   1991   13.7   12.9     95  11.78    185     16  305.6  341.2  307.8
  786.0   2150   12.9   12.1     95  11.37    210     16  306.4  340.9  308.5
  773.0   2290   12.2   11.3     95  11.03    190     17  307.1  340.6  309.2
  724.0   2841    9.4    8.5     94   9.74    220     23  309.9  339.9  311.7
  700.0   3125    8.0    7.1     94   9.12    215     23  311.3  339.7  313.0
  697.0   3160    7.8    7.0     95   9.10    222     21  311.5  339.8  313.2
  694.0   3196    7.5    6.7     94   8.93    230     19  311.6  339.4  313.2
  684.0   3314    6.7    5.5     93   8.38    250     19  311.9  338.1  313.5
  645.0   3794    3.2    1.0     86   6.44    235     17  313.2  333.6  314.4
  643.0   3819    3.0    0.8     85   6.35    239     18  313.3  333.4  314.5
  631.0   3971    1.9   -3.0     70   4.89    260     25  313.8  329.5  314.7
  618.0   4138    0.8   -7.2     55   3.62    257     23  314.3  326.2  315.0
  607.0   4283    1.8   -9.9     42   2.99    255     21  317.1  327.1  317.7
  586.0   4567    3.8  -15.1     24   2.03    265     31  322.7  329.8  323.1
  580.0   4650    4.4  -16.6     20   1.81    266     31  324.3  330.7  324.6
  535.0   5301    1.2  -21.8     16   1.26    274     29  328.0  332.6  328.3
  527.0   5421    0.4  -12.6     37   2.77    275     29  328.5  338.2  329.0
  517.0   5574   -0.3  -20.3     20   1.48    273     31  329.4  334.8  329.7
  500.0   5840   -2.5   -9.5     59   3.74    270     35  329.9  342.9  330.7
  497.0   5888   -2.9   -8.9     63   3.95    270     35  330.0  343.7  330.8
  451.0   6653   -6.9  -10.1     78   3.96    274     38  334.3  348.2  335.1
  439.0   6862   -8.4  -11.2     81   3.74    275     39  335.0  348.1  335.7
  429.0   7040   -9.7  -12.1     83   3.56    265     31  335.5  348.1  336.3
  402.0   7542  -13.3  -14.6     90   3.09    270     38  337.1  348.2  337.8
  400.0   7580  -13.5  -14.9     89   3.03    270     39  337.4  348.2  338.0
  399.0   7599  -13.6  -15.2     88   2.96    270     39  337.4  348.1  338.1
  388.0   7812  -14.9  -18.7     73   2.27    271     38  338.5  346.8  338.9
  377.0   8029  -15.5  -17.6     84   2.56    272     38  340.5  349.9  341.0
  320.0   9250  -23.1  -29.1     58   1.08    278     34  346.3  350.5  346.5
  300.0   9720  -26.7  -33.7     52   0.74    280     33  347.6  350.6  347.8
  279.0  10240  -29.9  -45.9     20   0.23    283     30  350.3  351.3  350.4
  264.0  10628  -33.4  -46.4     26   0.23    285     27  350.7  351.7  350.8
  250.0  11010  -36.9  -46.9     35   0.22    290     29  351.1  352.1  351.1
  238.0  11347  -40.1  -48.1     42   0.21    293     32  351.2  352.1  351.3
  209.0  12216  -46.5                         300     39  354.4         354.4
  200.0  12510  -48.7                         290     35  355.5         355.5
  180.0  13184  -52.9                         295     29  359.5         359.5
  152.0  14265  -59.6                         320     33  365.9         365.9
  150.0  14350  -60.1                         325     27  366.3         366.3
  134.0  15037  -63.3                         300     25  372.7         372.7
  119.0  15759  -66.6                         310     25  379.4         379.4
  106.0  16463  -69.9                         333     18  385.9         385.9
  105.0  16520  -69.8                         335     17  387.1         387.1
  100.0  16810  -69.5                           0     21  393.2         393.2
   76.2  18400  -76.1                         330      8  411.2         411.2
   70.0  18890  -75.1                         330     27  423.4         423.4
   50.0  20900  -67.3                          80     14  484.5         484.5
   30.0  24070  -58.1                          70     35  585.7         585.7
   20.0  26680  -49.1                          75     16  685.1         685.1

Station information and sounding indices

                             Station number: 47827
                           Observation time: 240530/1200
                           Station latitude: 31.55
                          Station longitude: 130.55
                          Station elevation: 31.0
                            Showalter index: 3.50
                               Lifted index: 7.51
    LIFT computed using virtual temperature: 7.55
                                SWEAT index: 392.09
                                    K index: 33.20
                         Cross totals index: 17.90
                      Vertical totals index: 18.70
                        Totals totals index: 36.60
      Convective Available Potential Energy: 0.00
             CAPE using virtual temperature: 0.00
                      Convective Inhibition: 0.00
             CINS using virtual temperature: 0.00
                     Bulk Richardson Number: 0.00
          Bulk Richardson Number using CAPV: 0.00
  Temp [K] of the Lifted Condensation Level: 289.99
Pres [hPa] of the Lifted Condensation Level: 938.98
   Equivalent potential temp [K] of the LCL: 332.79
     Mean mixed layer potential temperature: 295.27
              Mean mixed layer mixing ratio: 13.03
              1000 hPa to 500 hPa thickness: 5743.00
Precipitable water [mm] for entire sounding: 52.63
